MRCOOL® DIY® 5th Gen 36K BTU Ductless Mini-Split Heat Pump
The MRCOOL® DIY® 5th Generation 36K BTU Mini-Split Heat Pump delivers powerful, efficient heating and cooling for spaces up to 1,550 sq. ft. With a true DIY design, it installs quickly and easily—no special tools or professional assistance required—saving you time and money.
Easy, Fast Installation
-
DIY® QuickConnect® Line Set (sold separately) arrives pre-charged with R-454B refrigerant, eliminating vacuuming and cutting down installation time and costs.
-
DIYPRO® Cable replaces electrical conduit while providing added durability and resistance to weather and wildlife.
Smart Comfort Management
-
Control via wireless remote, SmartHVAC app (iOS & Android), or voice commands using Amazon Alexa or Google Assistant.
-
Follow Me technology adjusts airflow based on the remote’s location for even, personalized comfort.
-
Dry Mode reduces excess humidity, keeping your indoor environment comfortable.
Built to Last
-
Gold Fin® Condenser for superior corrosion resistance, ideal for coastal climates.
-
Limited Lifetime Warranty
-
7-Year Compressor Warranty
-
5-Year Parts Warranty
With its easy installation, smart technology, and dependable year-round performance, the MRCOOL® DIY® 36K BTU Mini-Split Heat Pump is the perfect solution for whole-home comfort.
|
FEATURE LIST
|
- NEEP ccASHP Listed
- Intertek listed 5031495
- Easy DIY installation
- Future-proof your investment with the included DIYPro® cable, eliminating the need for electrical conduit.
- Keep the included remote close by, and MRCOOL DIY®'s Follow Me® function will track the air temperature around you to ensure maximum comfort.
- The MRCOOL® Smart HVAC Controller® Module and App fully support Google Assistant & Amazon Alexa out of the box.
|
|
TONNAGE
|
3
|
|
VOLTAGE (V)
|
208/230
|
|
PHASE
|
1
|
|
CYCLE
|
60
|
|
MAX FUSE BREAKER (A)
|
15
|
|
MIN CIRCUIT AMPACITY (A)
|
3
|
|
MOUNT TYPE
|
Wall
|
|
COLOR
|
White
|
|
MAX COVERAGE AREA
|
1550 sqft
|
|
DECIBEL RATING LOW (DBA)
|
27.5
|
|
DECIBEL RATING HIGH (DBA)
|
55.5
|
|
NUMBER OF SPEEDS
|
5
|
|
OSCILLATION
|
Yes
|
|
LIQUID LINE SIZE
|
3/8
|
|
SUCTION LINE SIZE
|
5/8
|
|
FILTER TYPE
|
Reusable
|
|
AUXILIARY HEATER INCLUDED
|
No
|
|
AUXILIARY HEATER AVAILABLE
|
No
|
|
FAN ONLY OPTION
|
Yes
|
|
QUIET MODE
|
Yes
|
|
AUTO COOL
|
Yes
|
|
WIFI COMPATIBILITY
|
Yes
|
|
APP COMPATIBILITY
|
Yes
|
|
WORKS WITH IOS
|
Yes
|
|
WORKS WITH ANDROID
|
Yes
|
|
REMOTE CONTROL INCLUDED
|
Yes
|
|
UL LISTED
|
Yes
|
|
ETL LISTED
|
Yes
|
|
AHRI CERTIFIED
|
Yes
|
|
REGISTERED WARRANTY
|
Extended Limited Lifetime*
|
|
BASE PARTS WARRANTY
|
5
|
|
BASE COMPRESSOR WARRANTY
|
7
|
|
HAS BATTERIES
|
Yes
|
|
CONTAINS ELECTRONICS
|
Yes
|
|
CONTAINS CHEMICALS
|
Yes
|
|
CONTAINS AEROSOL
|
Yes
|
|
CONTAINS COMPRESSED GAS
|
Yes
|
|
PROPOSITION 65 WARNING
|
Yes
|
|
NET DEPTH (IN)
|
11.1
|
|
NET HEIGHT (IN)
|
14.25
|
|
NET WIDTH (IN)
|
49.57
|
|
NET WEIGHT (LBS)
|
48.72
|
|
GROSS DEPTH (IN)
|
18.74
|
|
GROSS HEIGHT (IN)
|
16.57
|
|
GROSS WIDTH (IN)
|
53.94
|
|
GROSS WEIGHT (LBS)
|
67.9
|
|
