5th Generation MRCOOL® DIY® OuttaSight® 6K BTU 230V One-Way Ceiling Cassette
Efficient, compact, and easy to install, the 5th Generation MRCOOL® DIY® OuttaSight® 6K BTU Ceiling Cassette is the perfect solution for heating and cooling spaces up to 200 sq. ft. Designed for true DIY installation, it requires no specialized tools or professional help—saving you time, effort, and money.
Key Features:
-
Coverage: Ideal for rooms up to 200 sq. ft.
-
Easy DIY Installation: Fits between standard 16" ceiling joists (including pre-manufactured I-joists) for a clean, flush look—no wall space or bulky ductwork required.
-
Flexible Design: Works perfectly in both new construction and retrofit projects.
-
Quick Connect® Ready: Pairs with MRCOOL® DIY® pre-charged Quick Connect® line sets (R-454B refrigerant) for fast, vacuum-free setup.
-
Eco-Friendly: Uses R-454B refrigerant for reduced environmental impact.
-
Better Air Quality: Advanced filtration system keeps indoor air fresh and clean.
-
Easy Maintenance: Elevation function lowers the panel for quick filter access.
-
Quiet Comfort: Operates with minimal noise for a more relaxing environment.
-
Smart Controls: Includes wireless remote, SmartHVAC app compatibility, and voice control with Amazon Alexa or Google Assistant.
Warranty:
-
Limited Lifetime Warranty on the unit.
-
7-Year Warranty on the compressor.
-
5-Year Warranty on parts.
Why Choose It?
The MRCOOL® OuttaSight® Ceiling Cassette blends sleek design, smart features, and eco-friendly performance—delivering efficient, reliable comfort in a space-saving package.
|
WORKS WITH
|
DIY 5th Gen Systems
|
|
FEATURE LIST
|
- Low Profile Installation
- Fits between 16" Ceiling Joists
- Works with Multi and Single Zone Systems
- Two-Stage DC motor
- Quiet Operation
- Multiple Operating Modes
- Remote Included
- Advanced Filtration
- Swing Technology
|
|
CFM
|
341 / 294 / 259 / 235 / 235
|
|
VOLTAGE (V)
|
208-230
|
|
PHASE
|
1
|
|
CYCLE
|
60
|
|
MAX FUSE BREAKER (A)
|
15
|
|
MIN CIRCUIT AMPACITY (A)
|
3
|
|
MOUNT TYPE
|
Ceiling
|
|
COLOR
|
White
|
|
RATED LOAD
|
0.8
|
|
MAX COVERAGE AREA
|
200
|
|
REFRIGERANT TYPE
|
R-454B
|
|
DECIBEL RATING (DBA)
|
35.5
|
|
DECIBEL RATING LOW (DBA)
|
23.5
|
|
DECIBEL RATING HIGH (DBA)
|
46.5
|
|
AIR FLOW DIRECTION
|
1-Way
|
|
LIQUID LINE SIZE
|
1/4
|
|
SUCTION LINE SIZE
|
3/8
|
|
BLOWER MOTOR RPM
|
1024/944/784
|
|
FILTER TYPE
|
Reusable
|
|
FAN ONLY OPTION
|
Yes
|
|
QUIET MODE
|
Yes
|
|
SLEEP MODE
|
Yes
|
|
AUTO COOL
|
Yes
|
|
WIFI COMPATIBILITY
|
Yes
|
|
APP COMPATIBILITY
|
Yes
|
|
WORKS WITH IOS
|
Yes
|
|
WORKS WITH ANDROID
|
Yes
|
|
REMOTE CONTROL INCLUDED
|
Yes
|
|
REGISTERED WARRANTY
|
Limited Lifetime Compressor
|
|
BASE WARRANTY
|
5-Year Part/7-Year Compressor
|
|
BASE PARTS WARRANTY
|
5 Years
|
|
REGISTERED COMPRESSOR WARRANTY
|
Limited Lifetime Compressor
|
|
BASE COMPRESSOR WARRANTY
|
7 Years
|
|
HAS BATTERIES
|
Yes
|
|
CONTAINS ELECTRONICS
|
Yes
|
|
CONTAINS CHEMICALS
|
Yes
|
|
CONTAINS AEROSOL
|
Yes
|
|
CONTAINS COMPRESSED GAS
|
Yes
|
|
PROPOSITION 65 WARNING
|
Yes
|
|
RESTRICTED STATES
|
GU;PR;VI
|
|
NET DEPTH (IN)
|
13.19
|
|
NET HEIGHT (IN)
|
8.98
|
|
NET WIDTH (IN)
|
50.31
|
|
NET WEIGHT (LBS)
|
45
|
|
GROSS DEPTH (IN)
|
22.48
|
|
GROSS HEIGHT (IN)
|
22.64
|
|
GROSS WIDTH (IN)
|
57.6
|
|
GROSS WEIGHT (LBS)
|
88
|
|
